型號
感光芯片 畫素(HxV)
解析度(MP)
快門
取像速度
(FPS)像素尺寸
Sensor Format
感光芯片尺寸 acA640-750um
acA640-750ucPYTHON 300 640 px x 480 px
0.3
Global
751
4.8 µm x 4.8 µm
1/4''
3.1 mm x 2.3 mm acA720-520um
acA720-520ucIMX287 720 px x 540 px
0.3
Global
525
6.9 µm x 6.9 µm
1/2.9''
5 mm x 3.7 mm acA800-510um
acA800-510ucPYTHON 500 800 px x 600 px
0.5
Global
511
4.8 µm x 4.8 µm
1/3.6''
3.8 mm x 2.9 mm acA1300-200um
acA1300-200ucPYTHON 1300 1280 px x 1024 px
1.3
Global
203
4.8 µm x 4.8 µm
1/2''
6.1 mm x 4.9 mm acA1440-220um
acA1440-220ucIMX273 1440 px x 1080 px
1.6
Global
227
3.45 µm x 3.45 µm
1/2.9''
5 mm x 3.7 mm acA1920-40um
acA1920-40ucIMX249 1920 px x 1200 px
2.3
Global
41
5.86 µm x 5.86 µm
1/1.2''
11.3 mm x 7.1 mm acA1920-150um
acA1920-150ucPYTHON 2000 1920 px x 1200 px
2.3
Global
150
4.8 µm x 4.8 µm
2/3''
9.2 mm x 5.8 mm acA1920-155um
acA1920-155ucIMX174 1920 px x 1200 px
2.3
Global
164
5.86 µm x 5.86 µm
1/1.2''
11.3 mm x 7.1 mm acA2040-55um
acA2040-55ucIMX265 1920 px x 1200 px
3
Global
55 3.45 µm x 3.45 µm
1/1.8''
7.1 mm x 5.3 mm acA2040-120um
acA2040-120ucIMX252 2048 px x 1536 px
3
Global
120
3.45 µm x 3.45 µm
1/1.8''
7.1 mm x 5.3 mm acA2440-35um
acA2440-35ucIMX264 2448 px x 2048 px
5
Global
35
3.45 µm x 3.45 µm
2/3''
8.4 mm x 7.1 mm acA2440-75um
acA2440-75ucIMX250 2448 px x 2048 px
5
Global
75
3.45 µm x 3.45 µm
2/3''
8.4 mm x 7.1 mm acA2500-60um
acA2500-60ucPYTHON 5000 2590 px x 2048 px 5 Global 60 4.8 µm x 4.8 µm 1'' 12.4 mm x 9.8 mm acA3088-57um
acA3088-57ucIMX178 3088 px x 2064 px 6 Rolling 59 2.4 µm x 2.4 µm 1/1.8'' 7.4 mm x 5 mm acA4024-29um
acA4024-29ucIMX226 4024 px x 3036 px 12 Rolling 31 1.85 µm x 1.85 µm 1/1.7'' 7.4 mm x 5.6 mm acA5472-17um
acA5472-17ucIMX183 5472 px x 3648 px 20 Rolling 17 2.4 µm x 2.4 µm 1'' 13.1 mm x 8.8 mm
